Support: pingRX Pro
pingRX Pro delivers professional-grade ADS-B detection for Detect and Avoid (DAA) onboard your UAS. Below you’ll find everything you’ll need to install, maintain, and learn about your dual band pingRX Pro. Please fill out a support ticket for advanced problems and questions.
FAQs
Frequently Asked Questions (FAQs)
What is the pingRX Pro?
The uAvionix pingRX Pro is a professional-grade, dual-band (978 MHz UAT + 1090 MHz ES) ADS-B receiver designed specifically for drones/UAS. At only 8 grams and housed in a rugged aluminum case, it delivers real-time traffic awareness by detecting and identifying nearby ADS-B-equipped aircraft, then seamlessly forwarding their position data via MAVLink to ArduPilot/Pixhawk-based autopilots and ground-station software. With its detachable remote-mount antenna, proven aviation-certified receiver technology (the same used in over half a million certified ADS-B installations worldwide), and simple plug-and-play integration, the pingRX Pro gives commercial and public-safety drone operators a lightweight, reliable “see-and-avoid” tool to enhance situational awareness and fly safer in shared airspace.
We need to have a means of validating the firmware version that these devices are on and ability to upgrade them if necessary.
We do not provide field update instructions for the pingRX Pro. All pingRX Pros are sent out with the same firmware.
I cannot find the user/install manual for the pingRX Pro.
The pingRX Pro is a fairly simple setup so we put together a quick start guide and provide the uAvionix MAVLink OEM Protocol ICD to supplement this.
Does the pingRX Pro have operational and storage temperature ratings?
The pingRX Pro has not been tested but has an operating temp of -45 to 80 degrees C.
Is there a way to get weather/NOTAMs in your MAVLink/serial interface?
There is no way at this time to receive that information from the pingRX Pro.
Is there a way to limit data received based on altitude?
Data can be filtered based on radius and altitude through your autopilot settings.
Can the performance of the pingRX Pro be degraded by flying over water?
No, flying over water should have no impact on performance of the pingRX Pro. However, there may be issues if the aircraft transmitting ADS-B is flying over water.
Is the MTL sensitivity (-84dB) conductive sensitivity or does it include the antenna gain?
It includes antenna gain.
What is the HS code and EAR_ECCN of the pingRX Pro?
The HS code is 8526910010 and the ECCN is EAR99
Does the pingRX Pro have an FCC ID?
The pingRX Pro is a receiver and does not require an FCC ID.
