SKU: UAX-90129-01

Airspace Awareness for UAS Operations

uAvionix FlightLine is an aviation-grade Surveillance Data Service Provider (SDSP) designed specifically for enterprise UAS operators. It delivers comprehensive, real-time situational awareness of nearby airspace traffic by harnessing uAvionix’s extensive network of ground-based dual-frequency ADS-B receivers, combined with scalable cloud infrastructure for efficient processing and display of target aircraft data.

This robust solution empowers UAS operators, UAS Service Suppliers (USS’s), and broader Unmanned Traffic Management (UTM) platforms with reliable, low-latency surveillance, enabling safer, more scalable Beyond Visual Line of Sight operations and supporting the industry’s growth in advanced airspace integration.

  • Product Details

    FlightLine is a cutting-edge, comprehensive airspace situational awareness tool that combines dual‑frequency ADS‑B receivers, optional computer vision detection of non-cooperative aircraft and a scalable cloud infrastructure for the processing and display of ADS-B equipped and detected aircraft and ground vehicle data — supporting controllers, drone operators, and UTM platforms.

Contact Sales

Why FlightLine

The FlightLine Surface Awareness System

The FlightLine system is a cutting-edge surface awareness solution designed to provide air traffic controllers with real-time visibility into aircraft and ground vehicle movements across an airport’s operational area. By leveraging Ground-Based Receivers (GBRs) and FAA-certified vehicle transponders (VTU-20s) receiving 978 MHz and 1090 MHz ADS-B data, FlightLine delivers precise tracking data for aircraft and ground-based vehicles to ATC tower displays, enhancing safety, efficiency, and situational awareness. This integrated system ensures full coverage of movement areas, enabling seamless coordination between controllers, pilots, and ground operators.

  • Ground-Based Receivers (GBR): Up to 4 per airport for full movement area coverage
  • ATC Displays: Installed at ground and local control positions for real-time awareness
  • Vehicle Transponders (VTU-20): FAA-certified units for operational vehicles
  • Scalable System:  Cloud-based service fully supported by uAvionix customer service and training

Operational Efficiencies for Your Airport

  • Improved arrival sequencing and runway loading
  • Improved departure sequencing
  • Better integration of vehicles in movement areas
  • Optimized operations in low visibility

Safety Enhancements Trusted by FAA

  • Improved arrival sequencing and runway loading
  • Improved departure sequencing
  • Better integration of vehicles in movement areas
  • Optimized operations in low visibility

What is SAI?

The FAA’s Surface Awareness Initiative (SAI) enhances runway safety by delivering real-time aircraft and vehicle tracking to air traffic controllers.

Goal: Reduce runway incursions and improve situational awareness at airports across the U.S.

Partnered with uAvionix to deploy the FlightLine system as a cost-effective, radar-free solution.

Live at airports including Austin, Indianapolis, Daytona, West Palm Beach, Orlando Sanford, Miami Executive, Tampa, and Jacksonville.

32 additional airports scheduled for deployment in 2025.

A new era for air traffic control – from Archie League (courtesy National Archives) to today’s SAI equipped tower

FAA Surface Awareness Initiative (SAI)

Operational Deployments of FlightLine

FAA Logo

Is FlightLine Coming to Your Airport?

The new FAA-funded solution to reduce runway incursions, improve awareness, and give you real-time insight into your movement areas is avaialable now.

Schedule time with us

Vehicle Tracking with VTU-20

Increase Runway Safety for Vehicle Operators

Airports that leverage FAA-certified VTU-20 on their vehicles in the movement area will achieve additional benefit from Surface Awareness deployment in the ATC Tower and Flight Operations. A live view of vehicles on runways and taxiways will provide increased situational awareness to the controllers and will allow for optimized efficiency providing clearances to enter the movement area. Vehicle operators can leverage a mobile version of the system to view traffic in the airfield in reference to their own vehicle position. Acting as any other ADS-B transponder, the vehicle also becomes visible to all aircraft with ADS-B in and leveraging Electronic Flight Bags (EFB) and a uAvionix Sentry or skyEcho2, this will significantly enhance safety during low visibility and snow operations with increased vehicle presence on the runway.

VTU-20 is FAA-certified under AC 150/5220-26 and provides real-time visibility to ATC and other aircraft of snowplows, sweepers, ops vehicles, and more.

Vehicle transponders are eligible for FAA grants in the US for airports that have surface awareness deployed and can be ordered through uAvionix.

Learn more about VTU-20

Download the VTU-20 DATA Sheet

FAQ’s

Knowledge Base

  • I was selected, how can we help?

    Your airport authority can help by designating a Point of Contact (POC) to coordinate the site survey and installation process. Additionally, providing access to preferred electrical contractors who are familiar with airport infrastructure can streamline the deployment and reduce installation time.

  • What are the benefits of vehicle transponders?

    Equipping airport vehicles with FAA-certified VTU-20 Vehicle Movement Area Transmitter (VMAT) enhances situational awareness for air traffic controllers by making vehicle movements visible on ATC displays. This improves safety during low-visibility conditions, reduces the risk of runway incursions, and helps integrate ground operations more efficiently into the airfield environment.

  • I have a Contract Tower, can I use SAI?

    While SAI is currently being deployed at FAA-operated ATC towers, contract towers may be eligible to integrate similar situational awareness tools. uAvionix can provide additional guidance on potential solutions and deployment options for contract tower environments.

  • Is the FlightLine Data Available for UAS Operations?

    Yes, FlightLine Data from SAI deployments at airports is combined with data from a network of uAvionix ADS-B receivers (978 MHz and 1090 MHz) deployed through the United States and parts of Europe and the UK.  FlightLine Data is avaiable via an API for integration with UTM or other systems for UAS operations, particularly those that require surveillance to permit BVLOS flights. For more information: Contact Us
