ping1090i
The world’s smallest and lightest ADS-B solution for sUAS
ping1090i is the world’s smallest, lightest, and most affordable full-range, dual-link Automatic Dependent Surveillance-Broadcast (ADS-B) transceiver with integrated Satellite Based Augmentation System (SBAS) Global Positioning System (GPS) and precision barometric sensor. At just 26 grams, it assists with Detect and Avoid (DAA) for Unmanned Aircraft Systems (UAS) operations in the National Airspace System (NAS).
All-in-one 1090MHz ADS-B, GPS, and Baro
Ping1090i detects aircraft threats on both 1090MHz and 978MHz within a 100 statute mile radius in real-time and allows nearby aircraft to see you on 1090MHz.
Approved in
United Kingdom
Approved for use in the United Kingdom as a CAP-1391 Basic Electronic Conspicuity Device (ECD). Visit the CAA page for more information on CAP-1391 and electronic conspicuity.
Approved in
Australia
Approved for use in Australia as a CAO 20.18 Basic Electronic Conspicuity Device (ECD). Visit the CASA page for more information on CAO 20.18 and electronic conspicuity.
The following required statement from the Federal Communications Commission (FCC) applies to United States based entities with the exception of direct sales to the U.S. Government and units directly exported by uAvionix:
This device has not been authorized as required by the rules of the Federal Communications Commission. This device is not, and may not be, offered for sale or lease, or sold or leased, until authorization is obtained.
Integrated WAAS GPS
The integrated uAvionix FYX GPS provides accuracy and integrity for protection against jamming and GPS anomalies.
Plug and Play with Your Autopilot
Ping1090i integrates seamlessly with Ardupilot and PixHawk based autopilots, getting you from setup to launch in only a few lines of code. Extend ping1090i’s hardware integrity to the rest of your platform with Auterion Skynode, the enterprise-ready autopilot.
| Specification | Value |
|---|---|
| Input Voltage | 11-28V
500mW Ave . 30W Peak (400us) |
| Size | 25x40x16mm |
| Weight | 26 grams |
| SDA/SIL | 1/1 (or 1/0 for CAP1391 devices in UK only) |
| Operating Temp | -45 to 70°C |
| Transceiver (Transmit) | |
| 1090MHz | 20W Nominal (43dBm) |
| Transceiver (Receive) | |
| MTL 1090MHz | -88dBm |
| Dynamic Range | -79 to 0dBm |
| MTL 978MHz | -93dBm |
| Dynamic Range | -90 to -3dBm |
| WAAS GPS | |
| Augmentation | SBAS |
| Sensitivity | -166dBm |
| Altimeter | |
| Range | -1000ft – 80,000ft |
Program your ping devices using the Ping Installer mobile applications for Android and iOS
